Michael Dollel

BEng Electrical and Electronic Engineering
BEng Peirianneg Drydanol Ac Electronig

Design and development process of a high-end
passive stereo four-way loudspeaker.

Proses ddylunio a datblygu
uchelseinydd pedair ffordd stereo goddefol drud.

The development process of a four-way passive stereo loudspeaker is presented
throughout this thesis, containing a summary of basic audio knowledge and profound
calculations on the housing and crossover of the speaker. Additionally, all decision
processes about different occurring problems are explained in-depth with reasoning. A
MATLAB program for the housing calculations is implemented. A model of the housing is
created using Autodesk Fusion 360. The simulations are carried out with Multisim Ni.
Circuit diagrams and board plans of the crossovers are created using Autodesk Eagle.
The results are comparted to a professional crossover from a high-end audio device
retailer. With this approach, a cost-efficient high-end passive loudspeaker with optimal
user experience and versatility is developed.

Cyflwynir y broses ddatblygu o uchelseinydd stereo goddefol pedair ffordd drwy gydol y traethawd hir hwn, sy'n cynnwys crynodeb o wybodaeth glywedol sylfaenol a chyfrifiadau dwys ar letya a thrawsrannydd yr uchelseinydd. Yn ogystal, mae’r holl brosesau penderfynu am wahanol broblemau sy'n digwydd yn cael eu hesbonio’n fanwl gyda rhesymau. Mae rhaglen MATLAB ar gyfer y cyfrifiadau lletya yn cael ei rhoi ar waith. Mae model o'r llety yn cael ei greu gan ddefnyddio Autodesk Fusion 360. Mae'r efelychiadau'n cael eu cynnal gyda Multisim Ni. Mae diagramau cylchedau a chynlluniau bwrdd y trawsrannydd yn cael eu creu gan ddefnyddio Autodesk Eagle. Mae'r canlyniadau'n cael eu cymharu â thrawsrannydd proffesiynol gan fanwerthwr dyfeisiau sain drud. Gyda'r dull hwn, datblygir uchelseinydd goddefol cost-effeithlon gyda'r profiad defnyddiwr a hyblygrwydd gorau posibl.
